Description
Energy Mizer® Dishwasher, conveyor type, 44″W x 25-1/8″D x 56-1/2″H, low temp chemical sanitizing or high temp sanitizing, dual tank design, (3) stage wash process (wash/power rinse/final rinse), (249) racks/hour, 19″ dish clearance, electric tank heat, auto start/stop, auto fill, automatic water control system, power rinse heater system, automatic soil purging system, stainless steel scrap accumulator, chemical resistant industrial heaters, table limit switch & rack save clutch system, removable curtains, stainless steel construction, includes (1) open & (1) peg rack, 1 HP wash motor, 1 HP rinse motor, 1/8 HP conveyor motor, UL, cULus, ETL-Sanitation
Documents
Spec Sheet
PDF file
Installation & Service Training 1
Document
Installation & Service Training 2
Document
Wiring Diagram
Document
Parts Manual
Owner's Manual
Spec Sheet E-Temp
Document
Installation & Service Training 4
Document
Installation & Service Training 3
Document
Owner's Manual
PDF file
Introduction & Operation Video
Video
Warranty
PDF file
Specifications
| Manufacturer | CMA Dishmachines |
|---|---|
| Series | Energy Mizer |
| Model | EST-44 |
| Replaces model(s) | EST-44/L-R, EST-44/R-L |
| Width | 44.00" |
| Depth | 25.13" |
| Height | 56.50" |
| Shipping weight | 662.00 lb |
| Freight class | 125 |
| Tank Heat | electric |
| Temperature | high/low temp (convertible) |
| Tank design | (2) tank with pre-wash |
| Construction | stainless steel |
| Rack Capacity | approximately (250) racks/hour |
| Certifications | cULus, ETL-Sanitation, UL |
