Description
Serv-Ware – Refrigeration – 73 in. Glass Door Bar Back Unit – Dimensions: 73.1″ W x 24.4″ D x 36.2″ H – Exterior Material: Black Painted Steel – Interior Material: Stainless Steel – Insulation Material: CFC Free Foam – Shelf Material: PVC Coated Wire – # of Shelves: 1 per Door – Voltage: 115 – Amps: 3 – Hz: 60 – Phase: 1 – Temperature Range: 33°F – 41°F – Refrigerant + Charge oz.: R290 / 4.59 oz. – BTU/H: 1771 – Defrosting: Every 6 Hours – Horsepower: 3/7 – Storage Capacity: 17.2 cu. ft. – Warranty – Parts on Labor on Entire Unit: 3 Years – Warranty – Compressor, Part Only: 5 Years
Documents
Specifications
| Manufacturer | Serv-Ware |
|---|---|
| Model | BB4-24G-HC |
| Replaces model(s) | BB73-24G, BB73-24G-HC |
| Width | 73.10" |
| Depth | 24.40" |
| Height | 36.20" |
| Shipping weight | 416.00 lb |
| Depth (front - back) | 22 - 26 inches |
| Top Finish | stainless steel top |
| Refrigeration Location | self-contained, side mounted |
| Door Swing | swing door(s) |
| Exterior Finish | black exterior |
| Width (side - side) | 73 - 96 inches |
| Door Type | glass door(s) |
| Door Qty | 3 doors |
| Certifications | CE, cULus Classified, ETL-Sanitation, UL EPH Classified |
